The 50kw Weichai diesel generator set needs to be debugged before installation and use in order to operate normally. Incorrect debugging can lead to the generator set not being used smoothly. The following are the debugging steps for the generator set:

1. Measurement of insulation resistance: The measurement of insulation resistance of the generator can determine the insulation status of all live parts to the casing. When the generator is in a cold state, do not bring any external leads for measurement and inspection.
2. Measurement of winding resistance: The resistance of the generator winding is not only related to the loss of the generator, but also has an impact on the excitation voltage, short-circuit current and other characteristic parameters of the generator. The size of the DC resistance of the winding is related to the wire specification and winding type. There are many methods for measuring the DC resistance of wires, usually using the bridge measurement method, which is both accurate and convenient.
3. Generator heating test inspection: Self excited AC generators rely on residual excitation to establish voltage, and for brushless excitation generators, the residual voltage is relatively high. When the excitation circuit is short circuited, there is still a certain output voltage. The newly assembled generator has no residual magnetism, so the stator winding of the exciter should be magnetized with direct current before starting. Generators that have been put on hold for a long time also need to be magnetized before they can be self excited for power generation before being reused.
4. Adjustment of excitation device.
5. Adjustment of the differential adjustment device.
6. Inspection of air filter.
7. Inspection of anti-condensation heaters.
8. The debugging of the control screen and the electrical part of the control system should be inspected and debugged before they can be put into operation.

The above are the precautions for the installation and debugging of a 50kw Weichai diesel generator set. Only correct installation and debugging can make the generator set produce its expected effect. When purchasing a Weichai generator set, please identify a legitimate manufacturer.
